Code for an autoencoder that remove noise in an image:
import numpy as np from tensorflow.keras import layers, models from tensorflow.keras.datasets import mnist import matplotlib.pyplot as plt # Load the MNIST dataset (x_train, y_train), (x_test, y_test) = mnist.load_data() # Filter the dataset to include only '2's x_train_2s = x_train[y_train == 2] x_test_2s = x_test[y_test == 2] # Normalize the data x_train_2s = x_train_2s.astype('float32') / 255. x_test_2s = x_test_2s.astype('float32') / 255. # Reshape the data to include the channel dimension x_train_2s = np.reshape(x_train_2s, (len(x_train_2s), 28, 28, 1)) x_test_2s = np.reshape(x_test_2s, (len(x_test_2s), 28, 28, 1)) # Add noise to the images noise_factor = 0.3 x_train_noisy = x_train_2s + noise_factor * np.random.normal(loc=0.0, scale=1.0, size=x_train_2s.shape) x_test_noisy = x_test_2s + noise_factor * np.random.normal(loc=0.0, scale=1.0, size=x_test_2s.shape) # Make sure all values are between 0 and 1 x_train_noisy = np.clip(x_train_noisy, 0., 1.) x_test_noisy = np.clip(x_test_noisy, 0., 1.) # Build the autoencoder input_img = layers.Input(shape=(28, 28, 1)) # Encoder x = layers.Conv2D(32, (3, 3), activation='relu', padding='same')(input_img) x = layers.MaxPooling2D((2, 2), padding='same')(x) x = layers.Conv2D(32, (3, 3), activation='relu', padding='same')(x) encoded = layers.MaxPooling2D((2, 2), padding='same')(x) # Decoder x = layers.Conv2D(32, (3, 3), activation='relu', padding='same')(encoded) x = layers.UpSampling2D((2, 2))(x) x = layers.Conv2D(32, (3, 3), activation='relu', padding='same')(x) x = layers.UpSampling2D((2, 2))(x) decoded = layers.Conv2D(1, (3, 3), activation='sigmoid', padding='same')(x) autoencoder = models.Model(input_img, decoded) autoencoder.compile(optimizer='adam', loss='binary_crossentropy') # Train the autoencoder autoencoder.fit(x_train_noisy, x_train_2s,epochs=50,batch_size=128) # Use the autoencoder to denoise the test images decoded_imgs = autoencoder.predict(x_test_noisy) n=4 plt.figure(figsize=(6, 20)) for i in range(n): # Display original ax = plt.subplot(10, 3, 3*i + 1) plt.imshow(x_test_2s[i].reshape(28, 28)) plt.title("Original") plt.axis('off') # Display noisy ax = plt.subplot(10, 3, 3*i + 2) plt.imshow(x_test_noisy[i].reshape(28, 28)) plt.title("Noisy") plt.axis('off') # Display denoised ax = plt.subplot(10, 3, 3*i + 3) plt.imshow(decoded_imgs[i].reshape(28, 28)) plt.title("Denoised") plt.axis('off') plt.show()
Code for recurrent neural network (RNN). Note that this code is for educational purposes only and is therefore not intended to be used to predict the stock market.
import numpy as np import random import matplotlib.pyplot as plt from keras.models import Sequential from keras.layers import Dense, SimpleRNN # Normalize the data y = np.array([9, 7, 6, 10, 8, 7, 11, 9, 6, 12, 10, 7, 11, 9, 7]) yn = (y - np.min(y)) / (np.max(y) - np.min(y)) train_size=10 train = yn[0:train_size] # Prepare training data X_train = [] y_train = [] step = 4 for i in range(step, len(train)): X_train.append(yn[i-step:i]) y_train.append(yn[i]) X_train = np.reshape(X_train, (len(X_train),step, 1))# Data, samples, time steps, features y_train = np.reshape(y_train, (len(y_train),1, 1)) # Set seed for reproducibility random.seed(40) # Define the RNN model model = Sequential() model.add(SimpleRNN(units=5, input_shape=(step, 1), activation="sigmoid")) model.add(Dense(units=1, activation="sigmoid")) model.compile(optimizer='adam', loss='mean_squared_error') model.summary() # Train the model history = model.fit(X_train, y_train, epochs=1000) # Plot the training loss plt.figure() plt.plot(history.history['loss']) plt.xlabel('Epochs') # Added xlabel plt.ylabel('Loss') # Added ylabel plt.title('Training Loss') # Added title plt.show() # Predict on training data y_pred_train = model.predict(X_train) y_pred_train = y_pred_train.flatten() # Prepare validation data valid = yn[train_size-step:len(yn)] X_valid = [] y_valid = [] for i in range(step, len(valid)): X_valid.append(valid[i-step:i]) y_valid.append(valid[i]) X_valid = np.reshape(X_valid, (len(X_valid),step, 1)) y_valid = np.reshape(y_valid, (len(y_valid),1, 1)) # Predict on validation data y_pred_valid = model.predict(X_valid) y_pred_valid = y_pred_valid.flatten() # Set time intervals t1 = np.arange(1, len(yn) + 1) t2 = np.arange(step+1, train_size + 1) t3 = np.arange(step+y_pred_train.shape[0]+1, len(yn) + 1) plt.figure(figsize=(8, 5)) plt.plot(t1, yn, linestyle="-", marker="o", color="blue", label="Actual values") plt.plot(t2, y_pred_train, linestyle="-", marker="o", color="red", label="Predicted values (training)") plt.plot(t3, y_pred_valid, linestyle="-", marker="o", color="green", label="Predicted values (validation)") plt.xlabel('Time Step') # Added xlabel plt.ylabel('Normalized Values') # Added ylabel plt.title('Actual vs Predicted Values') # Added title plt.legend() plt.show()
